8mm Luxury Best Vinyl Flooring SPC Home Depot
Manufacturing Process
Raw Material Mixing：PVC resin, limestone powder, stabilizers blended in hot–cold mixer; controlled at 120–125°C.
SPC Extrusion：Twin-screw extruder forms rigid core sheet; thickness sensors maintain 8mm uniformity.
Lamination：Wear layer + decor film laminated onto hot SPC core via 160–180°C heat fusion.
Cooling & Calibration：Multi-stage roller calibration ensures flatness and low internal stress.
CNC Cutting：Boards trimmed into standard dimensions; tolerance ±0.15 mm.
Click Milling：Four-side profiling via HOMAG/Weinig automatic routers.
IXPE/EVA Bonding：Optional acoustic pad hot-press bonded.
Final Inspection：Surface defects, locking precision, density, thickness tests.
Product Definition
8mm Luxury Best Vinyl Flooring SPC Home Depot refers to a rigid-core stone–polymer composite flooring engineered for high-traffic residential and light-commercial applications. It combines a dense limestone-PVC core, wear-resistant UV coating, and a click-lock system to deliver dimensional stability, dent resistance, and rapid installation efficiency.
Technical Parameters & Specifications
| Parameter | Specification |
|---|---|
| Total Thickness | 8.0 ± 0.2 mm |
| Wear Layer | 0.3 / 0.5 / 0.7 mm (optional) |
| Core Density | 2000–2100 kg/m³ |
| Board Size | 1220×183 mm / OEM custom sizes |
| Click System | Unilin / Valinge 2G / 5G |
| Surface Texture | Embossed, EIR, matte, stone texture |
| Fire Rating | ASTM E84 Class B / EN13501-1 Bfl-s1 |
| Formaldehyde | Zero emissions |
| Water Absorption | ≤0.05% |
| Underlayment | 1–2 mm IXPE/EVA optional |
Structure & Material Composition
UV Coating Layer：Anti-scratch, stain-resistant, anti-fading surface treatment.
Wear Layer：Transparent PVC film protecting from abrasion and micro-damage.
Decor Film：High-resolution printed layer offering wood, stone, and matte designs.
SPC Core：Limestone + PVC composite delivering rigidity, stability, and waterproof performance.
Underlayment (Optional)：Acoustic IXPE/EVA pad improving sound insulation and comfort.
Manufacturing Process
Raw Material Mixing：PVC resin, limestone powder, stabilizers blended in hot–cold mixer; controlled at 120–125°C.
SPC Extrusion：Twin-screw extruder forms rigid core sheet; thickness sensors maintain 8mm uniformity.
Lamination：Wear layer + decor film laminated onto hot SPC core via 160–180°C heat fusion.
Cooling & Calibration：Multi-stage roller calibration ensures flatness and low internal stress.
CNC Cutting：Boards trimmed into standard dimensions; tolerance ±0.15 mm.
Click Milling：Four-side profiling via HOMAG/Weinig automatic routers.
IXPE/EVA Bonding：Optional acoustic pad hot-press bonded.
Final Inspection：Surface defects, locking precision, density, thickness tests.
Industry Comparison (SPC vs WPC vs Laminate)
| Feature | SPC 8mm | WPC | Laminate |
|---|---|---|---|
| Core Density | High | Medium | Low |
| Waterproof Performance | 100% | 95% | No |
| Dent Resistance | Strong | Medium | Weak |
| Acoustic Comfort | Medium (higher with IXPE) | High | Low |
| Thermal Expansion | Minimal | Moderate | High |
| Commercial Suitability | High | Medium | Low |
Application Scenarios
Distributors：Stable retail-grade SKU for large retail systems similar to Home Depot.
EPC Contractors：Durable specification for hotel rooms, apartments, offices, retail stores.
Developers：Low-maintenance flooring for residential and rental projects.
Installers：Fast click-lock system for high-efficiency construction.
Core Pain Points & Solutions
Dimensional Stability Issues：High-density SPC core prevents deformation under temperature swings.
Dent Resistance：8mm structure improves compressive performance for furniture load points.
Moisture & Mold：Fully waterproof SPC avoids warping, swelling, and mold growth.
On-site Installation Efficiency：Click-lock system reduces labor and installation time by 40–60%.
Risk Warnings & Mitigation
Ensure wear layer ≥0.3 mm for commercial foot traffic.
Avoid low-density cores (<1900 kg/m³) prone to deformation.
Confirm click-lock accuracy to prevent joint failure.
Use flat and dry substrates (<2% moisture) for optimal performance.
Procurement & Selection Guide (≥6 Steps)
Define project environment (residential, commercial, humidity exposure).
Choose wear layer thickness based on foot traffic.
Confirm core density and stability test reports.
Select proper surface texture (EIR for realism, matte for anti-slip).
Confirm clicking system (Unilin/Valinge certification).
Evaluate IXPE/EVA pad for acoustic requirements.
Request third-party test data (fire, abrasion, dimensional stability).
Assess packaging design suitable for long-distance transportation.
Engineering Case Study
A 6,800 m² apartment renovation project adopted 8mm SPC with 0.5 mm wear layer and IXPE underlayment. Installation speed improved by 52%, substrate preparation cost reduced by 18%, and post-installation warranty claims dropped to 0.2% within one year. Core density and locking precision were identified as the key success factors.
FAQ
1. Is 8mm SPC better than 6mm? — Higher stability, better acoustic comfort, stronger dent resistance.
2. Does it require glue? — No, click-lock installation is glue-free.
3. Can SPC be used in kitchens? — Yes, it is fully waterproof.
4. Is underlayment mandatory? — Optional but recommended for sound insulation.
5. Does SPC fade under sunlight? — UV coating prevents discoloration.
6. Can damaged boards be replaced? — Yes, boards are individually replaceable.
7. Is SPC suitable for heavy furniture? — Yes, high dent resistance supports static loads.
8. What is the lead time? — Typically 20–30 days depending on SKU.
9. Can thickness tolerance affect installation? — Yes, must be controlled within ±0.15 mm.
10. Are Home Depot-grade products different? — Requires strict QC, packaging, and consistent SKU performance.
CTA: Request Quotation / Technical Data / Project Samples
For engineering specifications, pricing sheets, container loading plans, or certified samples, please contact our technical and procurement team for a formal quotation and project-based material recommendation.
E-E-A-T Author Credentials
This article is written by a senior flooring manufacturing engineer with 12+ years of experience in SPC/RVP production, quality control, and global OEM supply for large retail chains and commercial flooring contractors.
| Application |
Application :Whether it is the bedroom, living room, kitchen, laundry space and children's room in the home, or shopping malls, restaurants, playgrounds, churches, schools, libraries, science and technology museums, such as public places.
